Four parameters: NIBP,SpO2,Pulse Rate,Temperature
* SpO2 waveform, PR strength display
* 2.8 inch color LCD with real time display
* Storage/Review trend data up to 3888 groups, data save time interval settable
* Audio and visual alarm when parameters exceeded and sensor-off
* Built-in rechargeable Li-ion battery, up to 4 hour running time
* Automatic shutdown for power saving, shutdown time interval settable
* Via USB to connect with the computer, unique software for telemonitoring by transmitting data synchronously via internet
* Battery capacity indicatior and prompt when battery low
Technical Specifications
* NIBP
-Measure Method: Automatic oscillometric
-Patient: Adult and Pediatric
-Measurement unite: mmHg/kPa selectable
-Measurement mode: Manual, Auto, STAT
-Measurement Type: SYS, DIA, MAP
-Measurement interval in AUTO mode:1,2,3,5,10,15,20,30,45,60Min
-Measuring period in STAT mode: 5 Min
-Measure range:
-Adult:30～2550 mmHg; child: 30～160 mmHg
-Accuracy: 1 mmHg
-Alarm limits range:
-SYS : Upper limits70～250 mmHg, Lower limits 60～180 mmHg
-DIA : Upper limits 40～200 mmHg, Lower limits35～150 mmHg
-MAP : Upper limits 60～230 mmHg, Lower limits 50～160 mmHg
* SpO2
-Measure Range: 35～100%
-SpO2 Accuracy: 2%(70～99%), 3%(40～70%)
* Pulse Rate
-Pulse Rate Range: 0～254 bpm
-Pulse Rate Accuracy: 1 bpm
-Alarm limits range:
-SpO2 upper limits : 95～100% lower limits: 85～96%
-Pulse Rate：keep up with the heart rate
* Temperature
-Channel: 1
-Input: Body surface thermal-sensitive resistor temperature sensor
-Measurement Unit: °C/°F selectable
-Measure range: 0～50℃
-Alarm limits range: Upper limits 36～45℃ Lower limits 34～38℃
-Measure accuracy: 0.1℃
System specifications
-Alarm ON/OFF: controlled by general switch and parameter switch (two levels)
-Display mode: LED and 2.8’ color LCD screen
-Trend data: 3888 groups of SpO2, TEMP,SYS, DIA trend data, The record time interval can be set to 5 Sec. to 120 Sec. , so that the record time rang can be up to 128 hr.
-AC power adaptor
-Input: AC 100～240V, 50/60Hz, 0.7A
-Output: DC 5V，2.5A
-Internal battery
-Type: 2800mAh/3.7V Li-ion rechargeable battery
-Operating Time: 6 hours of stand-by time with a full battery
-Recharge time: 8 hours
-Dimension:280mm×190mm×100mm
-Net Weight : 1000g
